Proroute H685 - Installation and SIM Card Setup

Forallenquiriespleasevisitwww.proroute.co.uk





LAN:LANRJ45Ethernetport.
WAN:WANRJ45Ethernetport.
RST:sysresetbutton
PWR:DCpowersocket.DC7~40V
VCC:DCwirepositivepole.DC7~40V
GND:DCwireground
GND:Serialground
RX:serialreceiving
TX:serialtransmission
RST:resetrouter
DIO0:digitI/Oport0
IDO1:digit
I/Oport1
NC:noconnection

1.2 Antennaconnections.

ThePROROUTEUK/Euroversion has2antennaconnectionsforCellandWi‐Fiasfollows:

Feature ANT1 ANT2 ANT3 ANT4
Main Cellular
●
Wi-Fi
●


1.3 HowtoInstalltheunit

