ProSoft Technology MVI56E-MCM User Manual

Reference MVI56E-MCM ♦ ControlLogix Platform
User Manual Modbus Communication Module
Page 150 of 209 ProSoft Technology, Inc.
6.4 MVI56E-MCM Database Definition
This section contains a listing of the internal database of the MVI56E-MCM
module. This information can be used to interface other devices to the data
contained in the module.
Register Range
Modbus Low
Modbus High
Content
Size
0 to 5999
40001
50000
User Data
10000
10000 to 10009
50001
50010
Backplane Configuration
10
10010 to 10039
50011
50040
Port 1 Setup
30
10040 to 10069
50041
50070
Port 2 Setup
30
10070 to 12669
50071
52670
Port 1 Commands
2600
12670 to 15269
52671
55270
Port 2 Commands
2600
15270 to 15359
55271
55350
Misc. Status Data
80
15350 to 15359
55351
55360
Port 1 Aux Setup
10
15360 to 15369
55361
55370
Port 2 Aux Setup
10
15400
55401
Command Control
1
The User Data area holds data collected from other nodes on the network
(Master read commands) or data received from the processor (write blocks).
Additionally, this data area is used as a data source for the processor (read
blocks) or other nodes on the network (write commands).
Detailed definition of the miscellaneous status data area can be found in
MVI56E-MCM Status Data Definition (page 160).
Definition of the configuration data areas can be found in the data definition
section of this document and in MVI56E-MCM Configuration Data (page 151).
Command Control (page 160) shows the Database register definition in a table
for the Command Control block.
