ProSoft Technology MVI56E-MCM User Manual

Reference MVI56E-MCM ♦ ControlLogix Platform
User Manual Modbus Communication Module
Page 166 of 209 ProSoft Technology, Inc.
6.7.5 MCMCONTROL
This object contains the attributes to define a Master command. An array of
these objects is used for each port.
Name
Data Type
Description
WarmBoot
BOOL
Warm Boot
ColdBoot
BOOL
Cold Boot
SlaveControl
MCMSlaveControl
(page 166)
Allows the control of slave parameters.
CmdControl
MCMCmdControl
(page 166)
Allows for a disabled command to be sent to a
device (Master).
EventCmd
MCMEventCmd
(page 167)
Allows a command defined in ladder to be sent
to a device (Master).
SlavePollStat
MCMSlavePollStat
(page 167)
Request slave poll status for the port (Master).
Passthru
MCMPassthru
(page 167)
Contains PassThru objects required when
PortX.Type is set to a value between 2 to 4.
SlaveControl
Name
Data Type
Description
TriggerSlaveControl
BOOL
Trigger to Enable or Disable Slaves
PortNumber
INT
Slave Address
NumberOfSlaves
INT
Number of Slaves
BlockNumber
INT
Block ID number
SlaveIndexes
INT[200]
Slave Indexes
NumberOfSlavesProcessed
INT
Number of Slaves processed
EnableSlaves
BOOL
Set 0 to Disable or 1 to Enable Slaves
CmdControl
Name
Data Type
Description
TriggerCmdCntrl
BOOL
Trigger command control. User application will
activate this trigger
NumberOfCommands
INT
Number of commands per block (1 to 6)
PortNumber
INT
MVI56-MCM Port Number of master port (1 or
2)
CommandIndex
INT[6]
Stores the command indexes for command
control
CmdsAddedToQueue
INT
Number of commands added to queue
CmdControlBlockID
INT
Temporary variable to calculate control block
ID
CmdCntrlPending
BOOL
Auxiliary control command - prevents a second
request before acknowledgment is received
