4 Assembly/Disassembly
Do not set the conveyor on the discharge flap!
Otherwise it could be damaged.
Depending on the mounting accessories there are the following options for fastening the
conveyor
Mounting accessories
Necessary counter piece
Fastening the conveyor
3 clamps
Lever clamping ring
See the chap. "Technical
Data"
Lever tensioning ring and counter
flange
Lever tensioning ring and
adapting flange
Lever tensioning ring and
machine hopper
