ProTec Polymer Processing FG 204 - Page 41

ProTec Polymer Processing GmbH Foerdergeraet_FG201-FG206_BA_1v0_2018_en
41
Machine hopper: Mounting cover:
Stainless steel/ St. nickel-plated
Outlet Ø 35 und Ø 62 mm
1.40 Kg
Aluminium
2.10 Kg
Counter bead: Tensioning ring
Stainless steel
0.33 Kg
Steel, nickel-plated
0.17 Kg
After-filter: Holder for after- and central-filter:
PA / Al / Stainless steel
3.50 Kg
Steel, RAL 9005
0.60 Kg
