N93-582-02 Issue 1 NH Page 23 of 28 © Protec Fire Detection plc 2015
13.2 Entering and editing Test Group Text
20 characters of group text are provided, per Test Group by the Digilite® DL500.
To enter / edit the text for a particular group double click on the 'Group Text' cell for the address, which
opens up the text editor box for that group. Figure 13.2 illustrates the text editor box for group 27.
Enter the text as required (in capital letters), then click on the 'X' in the top right corner of the box to accept
the text.
Figure 13.2
13.3 Entering and Editing Panel 'Banner' Text
Two rows of 20 characters of panel text are provided by the Digilite® DL500. This text is displayed by the
Digilite® DL500 when the system is normal.
To enter / edit the panel text double click on the 'Banner Text' cells which opens up the panel text editor box
Figure 13.3 illustrates the text editor box for one row of the display.
Enter the text as required (in capital letters), then click on the 'X' in the top right corner of the box to accept
the text.
Figure 13.3
