Chapter 1 Introduction
Page: 1-8
PS3100 SERIES USER
′ S MANUAL
z SERIAL PORT :
3 x DB-9(COM 1/2/4), 1 x RJ45 (COM3),
+5/12V Selectable (COM 1~3)
z UNIVERSAL SERIAL BUS PORT :
4 x USB2.0 ports.
1 x USB2.0 on side bezel
z LAN FUNCTION :
1 x 10/100/1000 Mbps
z AUDIO FUNCTION :
1 x 2W Speaker
z VGA FUNCTION :
1 x DB-15 VGA Interface
z DIMENSION (
WxHxD):
300mm x 299mm x 135mm
z System Weight:
4.5kg
z LCD PANEL:
Type
XGA/SVGA
Max. Resolution
1024 x 768 / 800 x 600
Size/Type
10.4” / TFT
Viewing Angel (degree)
0~65 degrees
Pixel Pitch
0.206(W) x 0.206(H)/
0.088(W) x 0.264(H)
Brightness
300 / 230 cd / m
2
Signal Interface (bit)
TTL (18-bit)
LCD MTBF
20,000
Back Light MTBF (Hrs)
20,000
z TOUCH PANEL :
10.4” 5wire Analog resistive
.
