Chapter 3 Software Configuration
Page:3-4
PS3100 SERIES USER
′
S MANUAL
3-3. FLASH BIOS UPDATE
3-3-1. System BIOS Update:
Users of PS3100 Series can use the program “Awdflash.exe” contained
in the Utility Disk for system BIOS and VGA BIOS update.
3-3-2. To update VGA BIOS for LCD Flat Panel Display:
As a user of PS3100 Series, you have to update the VGA BIOS for the
specific LCD flat panel you are going to use. For this purpose, you need
two files. One is the “Awdflash.exe” file and the other one is the VGA
BIOS for ATI Rage Mobility M6 file for LCD panel display. Both files
must be provided by the vendor or manufacturer. When you get these
two files ready, follow the following steps for updating your VGA BIOS:
1. Install “Awdflash.exe” from Utility Disk to Drive C.
2. Insert the VGA BIOS file you have obtained from the vendor.
Type the path of Awdflash.exe and execute the VGA BIOS update
with file H15bxxxx.bin
3. C:\UTIL\AWDFLASH>AWDFLASH 31000LTX.bin
4. The screen will display as the table below:
FLASH MEMORY WRITER v8.XX
(C) Award Software 2001 All Rights Reserved
Flash Type – SST 49LF008A /3.3V
File Name to Program: 31000LTX.bin
Checksum: XXXXX
Error Message: Do You Want To Save BIOS (Y/N)
To Next Page
