Chapter 4 Award BIOS Setup
Page: 4-4
PS3100 SERIES USER
′
S MANUAL
4-3. THE STANDARD CMOS FEATURES
Highlight the〝STANDARD CMOS FEATURES〞and press the <ENTER>
key and the screen will display the following table:
Phoenix - AwardBIOS CMOS Setup Utility
Standard CMOS Features
Date (mm:dd:yy)
Time (hh:mm:ss)
Thu, Jun
22 2007
13 : 54 : 47
Item Help
▶ IDE Channel 0 Master
▶ IDE Channel 0 Slave
▶ IDE Channel 2 Master
▶ IDE Channel 2 Slave
▶ IDE Channel 3 Master
▶ IDE Channel 3 Slave
Video
Halt On
Base Memory
Extended Memory
Total Memory
[ HDS728080PLA380]
[ None]
[ None]
[ None]
[ None]
[ None]
[EGA/VGA]
[All, But Keyboard]
640K
514048K
515072K
Menu Level ►
Change the day,
month, year and
century
↑↓→←: Move Enter: Select +/-/PU/PD:Value F10:Save ESC:Exit F1:General Help
F5: Previous Values F6: Fail-Safe Defaults F7:Optimized Defaults
CMOS Setup screen
In the above Setup Menu, use the arrow keys to highlight the item and then use
the <PgUp> or <PgDn> keys to select the value you want in each item.
DATE:
< Month >, < Date > and <Year >. Ranges for each value are in the CMOS
Setup Screen, and the week-day will skip automatically.
TIME:
< Hour >, < Minute >, and < Second >. Use 24 hour clock format, i.e., for PM
numbers, add 12 to the hour. For example: 4: 30 P.M. You should enter the
time as 16:30:00.
