Chapter 4 Award BIOS Setup
PS3100 SERIES USER ′ S MANUAL
Page: 4-27
4-9. PC HEALTH STATUS
Choose 〝PC HEALTH STATUS〞 from the main menu, a display will
be shown on screen as below:
Phoenix - AwardBIOS CMOS Setup Utility
PC Health Status
Item Help
Shutdown Temperature
Current CPU Temperature
Vcore
5V
12V
[Disabled]
28℃
0.88V
4.89V
12.88V
Menu Level ►
↑↓→←: Move Enter: Select +/-/PU/PD:Value F10:Save ESC:Exit F1:General Help
F5: Previous Values F6: Fail-Safe Defaults F7:Optimized Defaults
PC Health Status Setup Screen
The PC Health Status Setup allows you to select whether to choose between
monitoring or to ignore the hardware monitoring function of your system.
SHUTDOWN TEMPERATURE:
This item allows you to set up the CPU Warning Temperature.
CURRENT CPU TEMPERATURE:
This item shows you the current CPU temperature.
VCORE:
This item shows you the current system voltage.
5V /12V:
Show you the voltage of 5V/12V.
