Page: A-1
SYSTEM
ASSEMBLY
This appendix contains exploded diagram of the system.
Section includes:
z Exploded Diagram for 2 Inch Thermal Printer Remove/ Install
z Exploded Diagram for 3 Inch Thermal Printer Remove/ Install
z Exploded Diagram for 3 Inch Thermal Printer Platen Block Remove/
Install
z Exploded Diagram for Thermal Printer Control PCB Remove/ Install
z Exploded Diagram for PS3100 CF Card Remove/ Install
z Exploded Diagram for PS3100 Mini PCIE Card Remove/ Install
z Exploded Diagram for PS3100 MSR Installation
z Exploded Diagram for PS3100 MSR Remove
z Exploded Diagram for PS3100 RAM Remove/ Install
z Exploded Diagram for PS3100 HDD Remove/ Install
APPENDIX
A
