Chapter 3 Software Configuration
PS3100 SERIES USER
′
S MANUAL
Page:3-5
If you want to save the original BIOS, enter "Y" and press < Enter >. If
you choose "N", the following table will appear on screen.
FLASH MEMORY WRITER v8.XX
(C) Award Software 2001 All Rights Reserved
Flash Type – SST 49LF008A /3.3V
File Name to Program: 31000LTX.bin
Checksum: XXXXX
Error Message : Are You Sure To Program (Y/N)
Select "Y", and the BIOS will be renewed. When you are refreshing the
BIOS, do not turn off or reset the system, or you will damage the BIOS.
After you have completed all the programming, the screen displays the
table below:
FLASH MEMORY WRITER v8.XX
(C) Award Software 2001 All Rights Reserved
Flash Type – SST 49LF004A /3.3V
File Name to Program: 31000LTX.bin
Checksum: XXXXX
Reset System or Power off to
accomplish update process!
F1: Reset F10: Exit
Please reset or power off the system, and then the Flash BIOS is fully
implemented.
