Chapter 4 Award BIOS Setup
Page: 4-20
PS3100 SERIES USER
′
S MANUAL
SUPER IO DEVICE:
The options for these items are found in its sub menu. By pressing the
<ENTER> key, you are prompt to enter the sub menu of the detailed options
as shown below:
Phoenix – Award CMOS Setup Utility
SuperIO Device
Item Help
Onboard Serial Port 1
Onboard Serial Port 2
[3F8/IRQ4]
[2F8/IRQ3]
Menu Level ►
↑↓→←:Move Enter: Select +/-/PU/PD:Value F10:Save ESC:Exit F1:General Help
F5: Previous Values F6:Fail-Safe Defaults F7:Optimized Defaults
Descriptions on each item above are as follows:
1. ONBOARD SERIAL PORT 1/2:
Select an address and corresponding interrupt for the first and second
serial ports.
ONBOARD Lan Boot ROM:
This item allows you to enable or disable Boot from Lan function.
ONBOARD SERIAL PORT 3/4:
Select an address and corresponding interrupt for the third and forth serial
ports
To Next Page
