Q80S_2014 14
PROTECO S.r.l. Via Neive, 77 - 12050 Castagnito (CN) ITALY Tel. +39 0173 210111 - Fax +39 0173 210199 info@proteco.net - www.proteco.net
AUTOMATIC programming mode, with OBSTACLE DETECTION
Before starting this programming procedure make sure that the TORQUE/POWER is not set too high:
in that case please adjust parameter in menu to reduce it.
Automatic programming procedure: the control panel automatically sets motors’ working
times and force as well as the sensibility level for the obstacle detection (amperometric).
1 Use buttons to move inside the menu, till the display shows:
2 Press and hold button for about 10 seconds.
The control panel starts the automatic programming procedure, the gate will:
• If open, it start closing till the limit switch bracket meets the motor
• Then it opens till the opening limit position
• Stops and reverses till the fully closed position
• The control unit automatically sets deceleration about 50cm before
the fully closed/open positions
3 Now working times, deceleration times and the level of sensibility for obstacle detection
have been automatically set.
4 Press button to go back to the top level menus,
then press button again till the display shows:
or wait the timeout (20 seconds) to exit
If further adjustments of the sensibility level for obstacle detection are needed,
please refer to setting in the FORCE menu.
4.2 PROGRAMMING menu
Press button and use to select menu ,
then press button to enter the PROGRAMMING menu: display will show
Use buttons to scroll the lower level menu.
4.2.1 Selecting the PROGRAMMING MODE
