Proteus PSS-2015C - Carton #2 Parts Identification List (Continued); Additional Carton #2 Hardware; Weight Plate Specifications

CARTON #2 PARTS IDENTIFICATION LIST
PARTS DESCRIPTION Q'TY
6 3/8" - 16UNC BOLT x 64mm 15
7 3/8" - 16UNC BOLT x 69mm 10
8 3/8" - 16UNC BOLT x 75m 4
9 3/8" - 16UNC BOLT x 89mm 2
10 3/8" -16UNC BOLT x 95mm 2
11 3/8" - 16UNC BOLT x 100mm 3
12 3/8" - 16UNC BOLT x 116mm 6
13 3/8" - 16UNC BOLT x 186mm 2
14 1/2" - 13UNC BOLT x 82mm 2
15 1/2" - 13UNC BOLT x 186mm 1
16 7/16" SOCKET HEAD BOLT x 38mm 1
17 M8 NYLON NUT 2
18 3/8" NYLON NUT 2
19 1/2" NYLON NUT 7
20 3/8" NUT 43
21 M8 WASHER x 2.5t 2
22 3/8" WASHER x 2t 55
23 1/2" WASHER x 2t 10
24 1/2" WASHER x 1t 10
25 3/8" WASHER x 4.5t 19
26 1/2" CAST BUSHING 10
27 3/8" CAST BUSHING 4
28 3/8" CAST BUSHING 14
29 3/8" SPACER 4
30 PLASTIC HOUSING 2
31 1/2 BROUZE CAST BASHING 4
CARTON #2
P
T
S
U
Q
-6-
