BASE SECTION ASSEMBLY PART I
1). PLACE BASE TUBE ( D ), CENTER FRAME BASE ( P ) & LEG PRESS SEAT TUBE ( G ) ON FLOOR,
FIT 8 PCS SQUARE PLUG ( 30 ) INTO ENDS OF ALL TUBES ( INCLUDING BASE TUBE /CENTER
FRAME BASE & LEG PRESS SEAT TUBE ).
2). ASSEMBLE THE BASE SECTION WITH BOLTS ( 12 ) WASHERS ( 25 ) & NUTS ( 20 ).
-8-
D
P
20
25
G
E3
25
E3
25
12(3/8"x116)
25
E3
E3
20
25
20
25
E3
E3
20
12(3/8"x116)
25
25
12(3/8"x116)
E3
CARTON # 1
