Proton Products InteliSENS PD30 Instruction Manual (Issue 1a)
Home page 3
Home page 4
- Gauge status - PID status
- Size of the last lump flaw
- Position of last lump flaw
- Lump flaw count
- Size of the last neck flaw
- Position of last neck flaw
- Neck flaw count
Press the button to access the function menu page.
Press the button to advance to “Home Page 5”.
- Gauge status - PID status
- Running average diameter
-Running maximum diameter
- Running minimum diameter
- Line speed (from one of the speed sources: user preset line
speed; measured line speed from the speed pulse input;
measured line speed from analogue input.)
- Calculated cumulative length of object
Press the button to reset above length to zero.
Press the button to access the function menu page.
Press the button to return to “Home Page 1”.
