Technical data to FD 150/E Lathe:
Voltage: 230 Volt
Frequency: 50/60 Hz
Capacity: 100 watt
Length between centres: 150 mm
Height of centres: 55 mm
Height via support: 33 mm
Capacity of inside jaw: 1–20mm
Capacity of outside jaw: 20 –60mm
Cross slide adjustment: 40 mm
Upper carriage adjustment: 60 mm
Spindle bore: 8.5 mm
Cone holding fixture, chuck side: for ER 11 collets
Tool holder for tools: 6x6
Noise level: <70dB(A)
Device dimensions: 360 x150 x150
Weight: approx. 4.5 kg
Spindle speeds:
-ingearbox stage 1: 800 –2800 rpm
-ingearbox stage 2: 1500 –5000 rpm
Noise/vibration information
The information on vibration and noise emission has been de-
termined in compliance with the prescribed standardised and
normative measuring methods and can be used to compare elec-
trical devices and tools with each other.
Thesevalues also allow apreliminaryevaluation of the loads
caused by vibrationand noise emissions.
Warning!
Depending on the operating conditionswhile operating the de-
vice, the actually occurring emissions could differ from the val-
ues specified above!
Please bear in mind that the vibration and noise emission can de-
viate from the values given in these instructions, depending on
the conditions of use of the tool. Poorly maintained tools, inap-
propriate working methods, different work pieces, too high a
feed or unsuitable work pieces or materials or unsuitable bits and
cutters can significantly increase the vibration load and noise
emission across the entire work period.
To more accurately estimate the actual vibration and noise load,
also take the times into consideration where the device is
switched off, or is running but is not actually in use. This can
clearly reduce the vibration and noise load across the entire work
period.
Warning:
•Ensure regular and proper maintenance of your tool
•Stop operation of the tool immediately if excessive vibration
occurs!
•Unsuitable bits and cutters can cause excessive vibration and
noises. Only use suitable bits and cutters!
•T
ake breaks if necessarywhen working with the device!
Only to be operated in closed rooms!
Do not dispose of the electrical device in the
household waste!
Always work with hearing protection!
Wear safety glasses!
Danger!
Ensure that no clamping pins or keys remain in the holes in
the chuck intended for this purpose after clamping!
Activation of the machine while clamping pins are in the chuck
holes can fling these out or lead to jamming during starting.
Be sure to ensure that the turning jaws are tightened securely be-
fore switching on the device since they could be loosened by
centrifugal force if there is no resistance.
Serious injuries or material damage
may result as aconsequence of this!
Set-up and commissioning
Danger!
Possibility of unexpected start-up! Injuries could be the result.
Therefore, always disconnect the mains plug for all adjust-
ment and maintenance work!
Setting up the device (Fig. 2a and Fig. 2b):
Caution!
Please check the device for any signs of damage in transit im-
mediately upon unpacking!Damaged packaging may already in-
dicate improper handling during transportation. Damage in tran-
sit must be claimed immediately with your dealer or the corre-
sponding transport company!
The following elements are included with the standard equip-
ment of the PROXXON FD 150/E lathe:
•Three-jaw chuck
•Chuck guard
•Travelling lathe centre
•Set of tools
•Tool holder
DANGER!
