Proxxon FD 150/E - Inserting the Collets (Fig. 16); Disposal

-23-
Caution:
Never tighten the swivel nut if no workpiece was inserted.
Inserting the collets (Fig. 16)
1.
Usethe wrench 1supplied with the machine to hold the main
spindle
2atthe provided flat surfaces and screw off the chuck
3f
rom the main spindle.
2.
Thoroughly clean the fit for the collet holding fixture 4inthe
main
spindle.
3.
Utilise the collet 5and slightly unscrew the swivel nut 6.
4.
Insert the appropriate workpiece in the collet and tighten the
swivel
nuts 6with the wrench 7provided with the collet set.
Disposal:
Do not disposeofthe device in the household waste! The device
containsmaterials that can be recycled. If you have questions
concerning this topic, please contact your municipal disposal
company or other appropriate municipal institutions.
EC Declaration of Conformity
Name
and address:
PROXXON
S.A.
6-10,
Härebierg
L-6868
Wecker
Product
designation: FD 150/E
Article
No.: 24150
In
sole responsibility,wedeclare that this product conforms to
the
following directives and normative documents:
EU EMC Directive 2014/30/EU
DIN EN 55014-1 /05.2012
DIN EN 55014-2 /11.2014
DIN EN 61000-3-2 /03.2015
DIN EN 61000-3-3 /03.2014
EU MachineryDirective 2006/42/EC
DIN EN 62841-1/07.2016
Date: 18.09.2017
Dipl.-Ing. Jörg Wagner
PROXXON S.A.
Machine Safety Department
The CE document authorized agent is identical with the signatory.
