Installation and Operating Instructions
SDC 204 1316BED035-10B-E Date 12/06
- 16 -
Status display
Solar circuit pump
Symbol rotates when the solar circuit
pump is switched on
Switching output 1 is active Appears if switching output 1 is active
(on).
Switching output 2 is active Appears if switching output 2 is active
(on).
Switching output 3 is active Appears if switching output 3 is active
(on).
Indicates a system error or
incorrect code entry
Display flashes if an error occurs in the
system.
Lights up if the wrong code is entered.
Safety question for value
changes with save facility
Value input can be
refused or
accepted .
Operating hours, yield for
storage cylinder
Appears together with operating hours
or yield
