Installation and Operating Instructions
SDC 204 1316BED035-10B-E Date 12/06
- 19 -
8.1 Overview
The diagram shows the entire menu structure of the Solareg Vision Plus.
i
Only the configuration-specific symbols are displayed.
Info Program Manual operation
Basic setting
I I I I
Current collector temperature /
Collector 1
Maximum temperature of
storage cylinder1
Pump1 off/on Collector protection
function
off/on
Minimum collector temperature /
Collector 1
Storage cylinder1 Tdmax
(Td on)
Pump2 / Valve1
off/on
Collector protection
temperature
Maximum collector temperature /
Collector 1
Storage cylinder1 Tdmin
(Td off)
Heating / Cooling /
Temperature
differential controller
off/on
Re-cooling
off/on
Current storage cylinder temperature
/ storage1 at bottom
Maximum temperature of
storage cylinder2
Re-cooling
temperature
Minimum storage cylinder temperature
/ storage1 at bottom
Storage cylinder2 Tdmax
(Td on)
Tube collector-
off/on
Maximum storage cylinder temperature
/ storage1 at bottom
Storage cylinder2 Tdmin
(Td off)
Yield estimation off/on
Current storage cylinder temperature
storage2 at bottom / collector2
Minimum pump rotating
speed in %
Glycol type
Minimum storage cylinder temperature
storage2 at bottom / collector2
Start temperature
Heating / cooling
Glycol percentage
Maximum storage cylinder temperature
storage2 at bottom / collector2
Hysteresis temperature
Heating / cooling Td
Volume flow
Current collector temperature - return
line
Temperature differential
controller:
Maximum temperature of
the heating target Tmax
Controlling time in
seconds
Current temperature
heating / cooling /
differential controller heating source
Temperature differential
controller:
Minimum temperature of
the heating source Tmin
Storage cylinder priority
Current temperature
frost protection sensor / differential
controller heating target / univ.
measuring point T6
Temperature differential
controller:
Hysteresis Tdmax
Frost protection
off/on
Operating hours – pump1 Temperature differential
controller:
Hysteresis Tdmin
Frost protection sensor
assignment
Yield storage1 Timeframe start
1,2,3 for the independent
controller, 4 for the tube
collector function
Frost protection:
start temperature
Operating hours – pump2 Timeframe stop
1,2,3 for the independent
controller, 4 for the tube
collector function
Independent controller
assignment:
Cooling, heating,
temperature differential
controller
Yield storage2 Set time Sensor assignment for
the independent controller
Select basic configuration
