Installation and Operating Instructions
SDC 204 1316BED035-10B-E Date 12/06
- 23 -
Display
Parameter -- Value
Meaning Value range
Factory
setting
0 -- 0
Collector protection 0 = off
1 = on
0 = off
1 -- 120 °C
Start temperature for the collector protection
110..150°C 120°C
2 -- 0
Re-cooling function (only when collector
protection is on)
0 = aus
1 = ein
0 = aus
3 -- 40 °C
Target temperature for the storage after
collector protection activity
30..90°C 40°C
4 -- 0
Time controlled circulation with tube
collectors
0 = aus
1 = ein
0 = aus
5 -- 0
Yield estimation off/on 0 = aus
1 = ein
0 = aus
6 -- 0
Glycol type 0...10 0
7 -- 50
Glycol percentage 0 ... 100%
5% - Schritte
50
8 -- 1,0
Volume flow: Litter per impulse - flow meter 0,5 … 25 l/I
0,5l - Schritte
1,0
9 -- 240
Time controlling in s 30...480 240
10 -- 1
Storage priority 1...2 1
11 -- 0
Frost protection on/off 0 = off
1 = on
0
12 -- 6
Sensor assignment – Frost protection 1...6 6
13 -- 3
Start temperature for the frost protection
function
-20 °C ... +7 °C 3
14 -- 0
Select cooling
thermostat or
temperature differential controller
0 = aus
1 = cooling
2 = heating
3 = temperature
differential controller
0
15 -- 5
Sensor assignment for the independent
controller (source)
1...6 5
16 -- 0
Select configuration 0...4 0
Glykol types (point 6):
0 Anro 6 Tyfocor L5.5
1 Ilexan E, Glythermin 7 Dowcal 10
2 Antifrogen L 8 Dowcal 20
3 Antifrogen N 9 Dowcal N
4 Ilexan E 10 Tyfocor LS
5 Ilexan P
