6 CONTROL MENU TREE
The next few pages of this manual show the structure of the menu and explain in a schematic way the operation of the FluorPen. The
schematic diagrams show the Main Menu, first-level Sub-Menus and second-level Sub-Menus.
• The blue color represents the Main Menu and its Options.
• The yellow color represents the first-level Sub-Menus and their Options.
• The green color represents the second-level Sub-Menus and their Options.
• Full-line arrows are used to indicate the SET key operations.
• Dashed-line arrows are used to indicate the MENU key operations.
