PSI FluorPen FP 110 Instruction Guide

Page | 8
2.1 TECHNICAL SPECIFICATION
FluorPen and PAR-FluorPen
Protocols
Ft – instantaneous chlorophyll fluorescence
Quantum Yield
OJIP
Non-photochemical quenching
Light curve
Photosynthetically Active Radiation (measured as PPFD) – PAR-FluorPen only
LED emitter
Blue (470 nm), other wavelengths on request
Saturating pulse Illumination
Up to 3,000 µmol(photon).m
-2
.s
-1
(adjustable from 10 to 100%)
Actinic Illumination
Adjustable from 10 to 1,000 µmol(photon).m
-2
.s
-1
Measuring Illumination
Up to 0,09 µmol(photon).m
-2
.s
-1
per pulse (adjustable from 10 to 100%)
Detector
PIN photodiode with bandpass filters
Wavelength range from 667 to 750 nm
Internal memory capacity
Up to 16 Mb
Internal data logging
Up to 149,000 measurements (depending on protocol)
Data transfer
USB cable
Bluetooth (transfer up to 3Mbps for distance up to 20m)
PC software
FluorPen 1.1 (Windows 7 and higher)
Battery
Li-Ion rechargeable battery
Capacity 2000 mAh
Max. charging current 0.5 A
Charging via USB port - PC, power bank, USB charger, etc.
48 hours typical with full operation
Low battery indicator
Sample holder
Standard leaf-clip (FP 110/S)
Detachable leaf-clip (FP 110/D)
Probe (FP 110/P)
Display
Graphical display
Keypad
Sealed, 2-key tactile response
Turns off after 5 minutes of no use
Built in GPS module
Ultra-high sensitivity down to -165dBm
High accuracy of <1.5 m in 50% of trials
Size
134 x 65 x 33 mm
Weight
188 g
Operating conditions
Temperature: 0 to +55 °C
Relative humidity: 0 to 95 % (non-condensing)
Storage conditions
Temperature: -10 to +60 °C
Relative humidity: 0 to 95 % (non-condensing)
Warranty
1-year parts and labor
