Chapter 5: On-Site Replacements and Upgrading
42
3. Ensure that the RTM’s latches are open. The latches have a locking mechanism that will need to be
pressed in order to open the latches.
4. Holding the RTM by its latches, align the RTM in the MPS1000’s card guides.
5. Slide the RTM gently straight into the empty slot, keeping the card level. Do not apply too much
pressure, particularly if you feel resistance. You should feel the pin connectors on the rear of the RTM
meet the backplane.
6. Continue to slide the RTM into the slot until the latches touch the extrusions on either side of the slot.
7. Press down on the latches to guide the RTM the rest of the way into the slot and lock it into place. You
will hear a click as the latches are closed and the RTM is set into place.
8. After insertion, tighten the captive screws on the latches.
9. ENET B (Ports “B”) should be connected using the supplied Crossover Cable. ENET A (Ports “A”)
should not be connected with a Crossover Cable. Using the Crossover Cable only applies to the 16-
port version.
Battery Instructions
The CPC358 has a lithium battery on it. The battery is user replaceable. In the event the battery
must be replaced, dispose of the battery in the proper manner.
Do not dispose of battery in fire. Do not disassemble battery or attempt to recharge it.
