Chapter 6: Configuration Settings
46
16-Port Configuration
For each CPC358, the DIP switch setting for SW1-1 must be in the Closed (ON) position for the
16-port MPS1000, as shown in Table 6-4, “SW1 DIP Switch Settings for MPS1000 16-Port
Version,”. DIP switches SW1-2 through SW1-4 are not used for this configuration and must be
left in the Open (OFF) position.
Table 6-4:SW1 DIP Switch Settings for MPS1000 16-Port Version
SW1 Closed (ON) Open (OFF)
Position 1 X
Position 2 X
Position 3 X
Position 4 X
