PUDU T300 Operation Guide
Version: V1.0.2 Operation Guide
32
6. Interface Description
Under the interface window, there are external interfaces that can be used for hardware expansion
and device debugging. The specific interface specifications are as follows:
No. Name Description
1 Power supply interface 24V (battery voltage), maximum output current of
2.5A. DC plug pin diameter: Ø2.5mm
2 USB USB 2.0, for data communication with external
devices
3 IO Used for signal communication of external optional
accessories
4 SIM card slot Supports Nano SIM card
5 OTG Used for device debugging
