Pulsar 200 NS User Manual

14. Odometer : The Odometer shows the total distance
that the vehicle has covered. Odometer can not be
reset to ‘Zero’.
15. Digital Clock : It indicates time in HR : MM
(AM/PM)
16. Coolant Temperature Indicator ( ) : It blinks
0
when engine coolant Temperature is more than 115
centigrade.
17. Low Battery Indicator : It indicates battery needs
charging.
18. Trip Meter : Trip 1 & Trip 2 shows the distance
traveled since it was last reset to zero.
11. Service Reminder ( ): ‘Wrench’ symbol glows
when ODO meter reading reaches to set Kms. for
service. This Icon will flash at -
st nd
1 : 450 km 2 : 4950 km,
rd th
3 : 9950 km, 4 : 14950 km
and subsequently at each 5000 kms. Icon will
continue to glow till it is reset. This icon is to be
reset after service is carried out.
12. Low Oil Pressure Indicator ( ) : It blinks when
engine oil pressure is low.
13. Speedometer: Vehicle speed will be displayed in
digital form in Km / Hr.
Speedometer Details
9
13
15
14
16
11
17
18
12

Pulsar 200 NS Specifications

General

Displacement	199.5 cc
Transmission	6-speed
Fuel System	Fuel Injection
Rear Suspension	Nitrox mono shock absorber with Canister
Front Brake	280 mm Disc
Rear Brake	230 mm Disc
Fuel Tank Capacity	12 liters
Bore x Stroke	72 mm x 49 mm
Clutch	Wet multi-plate
Front Tyre	100/80-17
Rear Tyre	130/70-17
Length	2017 mm
Width	804 mm
Wheelbase	1363 mm
Ground Clearance	167 mm
Seat Height	805 mm
Engine Type	4-stroke, SOHC 4-valve, Liquid Cooled, Triple Spark
Max Torque	18.3 Nm @ 8000 rpm
Front Suspension	Telescopic forks
Frame Type	Perimeter Frame
Height	1195 mm
