E
G
F
Control Switches
Right Handle Bar Switches
E. Head Light Switch : It has 3 positions.
: All lamps 'OFF'.
: While engine running, Tail lamp,
Meter lamp and Pilot lamp/s ‘ON’.
: While engine running, Head lamp,
Pilot lamp/s, Tail lamp and Meter
lamps ‘ON’.
F. Starter Button :
Starter button operates the electric starter
when clutch lever is depressed with
transmission in any gear.
It is recommended to start the engine with
the transmission in neutral.
G. Engine Kill Switch :
The engine kill switch is for emergency
use. During emergency move the engine
kill switch to the ‘OFF’ ( ) position.
Speedometer display will work when both Ignition
switch & kill switch are in ‘ON’ position.
CAUTION : While starting ensure that
engine kill switch is in ON ( ) position.
Keeping the kill switch in OFF position,
engine will not start.
13
