Pulsar 200 NS User Manual

S
M
Set
Mode
TRIP 1/2
3. Clock Reset :
• Digital clock indicates time in HR & MM separated
by colon ‘:’
• It is 12 hour clock.
• Initially ‘:’ will be blinking
• Clock setting is possible in TRIP 1 mode only.
1.
Press mode push button
for less than 2 sec.
TRIP1 Mode selected
2.
Press mode & set
push button together
for more than 2 sec.
Press mode button for
less than 1 sec.
Press set button for
less than 1 sec.
Press mode & set
button together for
more than 2 sec.
Clock set mode is
selected & no editing
is carried out for
more than 5 sec.
‘:’ stops blinking
Digits starts blinking
Hour digits will
increases by one.
Minutes digits will
increases. If mode/set
button is pressed
continuously then digits
will stop blinking.
Set value will be saved
Exit clock setting mode
Digits stop blinking
‘:’ start blinking
Auto exit without saving
set value.
If engine/vehicle rpm is
given then system will
exit from clock set mode
without saving set value.
3.
4.
5.
6.
Speedometer Setting
11

Pulsar 200 NS Specifications

General

Displacement	199.5 cc
Transmission	6-speed
Fuel System	Fuel Injection
Rear Suspension	Nitrox mono shock absorber with Canister
Front Brake	280 mm Disc
Rear Brake	230 mm Disc
Fuel Tank Capacity	12 liters
Bore x Stroke	72 mm x 49 mm
Clutch	Wet multi-plate
Front Tyre	100/80-17
Rear Tyre	130/70-17
Length	2017 mm
Width	804 mm
Wheelbase	1363 mm
Ground Clearance	167 mm
Seat Height	805 mm
Engine Type	4-stroke, SOHC 4-valve, Liquid Cooled, Triple Spark
Max Torque	18.3 Nm @ 8000 rpm
Front Suspension	Telescopic forks
Frame Type	Perimeter Frame
Height	1195 mm
