Pulsar 200 NS User Manual

Rear Seat / Tool Kit
Tool Kit
A
Tool Kit Location
• It is located below the ‘Rear seat’.
• 2 rubber straps are provided to hold the
tool kit.
Removal of Rear Seat
• Insert Key into lock (A)
• Turn the key clock wise.
• Pull upward front end of ‘Rear seat’
• Take out ‘Rear seat’
CAUTION : Always fit rubber strap for
locking tool kit.
14

Pulsar 200 NS Specifications

General

Displacement	199.5 cc
Transmission	6-speed
Fuel System	Fuel Injection
Rear Suspension	Nitrox mono shock absorber with Canister
Front Brake	280 mm Disc
Rear Brake	230 mm Disc
Fuel Tank Capacity	12 liters
Bore x Stroke	72 mm x 49 mm
Clutch	Wet multi-plate
Front Tyre	100/80-17
Rear Tyre	130/70-17
Length	2017 mm
Width	804 mm
Wheelbase	1363 mm
Ground Clearance	167 mm
Seat Height	805 mm
Engine Type	4-stroke, SOHC 4-valve, Liquid Cooled, Triple Spark
Max Torque	18.3 Nm @ 8000 rpm
Front Suspension	Telescopic forks
Frame Type	Perimeter Frame
Height	1195 mm
