Pulsar FlowCERT LITE User Manual

Page 105
Bargraph
P829 Bargraph
By default the bargraph will be representative of the reading obtained, as
determined by the Mode P100. This parameter is automatically set to the
correct default option when selecting the Mode P100 and Xducer (P101),
and under normal circumstances will not require changing.
The options, dependant on the value entered for Mode P100, are as follows:
Option
Description
1 = Level
Bargraph will be representative of level.
2 = Head (Default)
Bargraph will be representative of head.
3 = Flow
Bargraph will be representative of flow.
mA Output Parameters
Range
P830 mA Range
This parameter determines the range of the mA output, from the following.
Option
Description
0= Off
mA output disabled.
1= 0 to 20 mA
mA output directly proportional to the mA mode
(P831), so if the reading is 0% the output is 0 mA. If
the reading is 100% the output is 20 mA.
2= 4 to 20 mA
(Default)
mA output directly proportional to the mA mode
(P831), so if the reading is 0% the output is 4 mA. If
the reading is 100% the output is 20 mA.
3= 20 to 0 mA
mA output inversely proportional to the mA mode
(P831), so if the reading is 0% the output is 20 mA. If
the reading is 100% the output is 0 mA.
4= 20 to 4 mA
mA output inversely proportional to the mA mode
(P831), so if the reading is 0% the output is 20 mA. If
the reading is 100% the output is 4 mA.
