Pulsar Infinity PS-2SD - Installation Parts and Assemblies

Pulsar® Infinity Operation and Installation Manual – Water Treatment 12
3.3 Installation Parts and Assemblies
Part Description Part Number
A - (2) Adjustable Saddle Clamp Assembly for 2” [50.8 mm] pipe 73096
B - (2) Adjustable Saddle Clamp Assembly for 1-1/2” [38.1 mm] pipe 73096
C - (2) 5” x 1/2” [127 mm x 12.7 mm] MNPT Pitot tube
Refer to Appendix A for Pitot Tubes for 2 ½” and 3” pool piping
73086
D - (3) 1/2” [12.7 mm] FNPT x 1/2” [12.7 mm] FNPT PVC Ball Valves 74061
E - (4) 1/2” [12.7 mm] MNPT x 5/8” [15.9 mm] O.D. Tubing Connector
- W10MC8
71918
F - 12’ X 5/8” [365.76 cm X 15.9 mm] O.D. LLDPE Tubing 73095
G - (2) 1/2” [12.7 mm] PVC Closed Nipples 71611
