Pulsar® Infinity Operation and Installation Manual – Water Treatment 22
7 Feeder Views
7.1 Feeder Assembly View (standard installation)
Note: Quantities listed below represent the number of parts shipped with the feeder. Part numbers are for procurement of 1 individual spare part
unless otherwise stated.
Part Description Qty Part Number
Pulsar® Infinity Feeder
Complete Feeder assembly 1 74444
Pressure Cap Threaded Cap with Handle 1 73105
Seal Cap Inner Seal Cap 1 73091
O-ring O-ring Seal 2 (1 spare) 73094
Cartridge Assembly SDCH
Cartridge for Pulsar® Infinity Tablets
1 73110
Nozzle Standard SDCH Nozzle 1 73085
Nozzle Protection basket Filter basket for nozzle protection 1 73180
73110
Cartridge
Assembly
SDCH
73094
O-ring
73085
Nozzle
73091
Seal Cap
73105
Pressure Cap
73180
Nozzle protection
basket
