Pulsar® Infinity Operation and Installation Manual – Water Treatment 19
4.2.2 Feed Rate Tables
Pool & Spa
Cartridge
Setting
Inlet Flow Rate - gpm
0.5 1 1.5 2 2.5 3 3.5 4 4.5
Output Rate (lbs. Av. Cl/Day)
A 1.5 2 2.4 3.2 4.5
B 1.6 2.1 2.6 3.4 5
C 1.7 2.2 2.8 3.6 5.5
D 1.1 1.8 2.3 3 3.8 6.5
E 1.2 1.9 2.4 3.2 4 7.5
F 0.3 0.6 0.8 1.3 2 2.5 3.4 4.2 8
G 0.4 0.7 0.9 1.4 2.1 2.6 3.6 4.4 8.5
H 0.5 0.8 1 1.5 2.2 2.7 3.8 4.6 9
4.2.3 Controlling Chlorine Output With an ORP
1. Refer back to ORP schematic section 3.1.1.
NOTE: To use with an ORP, set the cartridge feed rate setting to H and fully open the inlet ball valve to allow maximum flow rate
through the feeder.
Use Higher Flow Rates
