Pulsar® Infinity Operation and Installation Manual – Water Treatment 16
4.1 Pre-Startup Procedure (continued)
4.1.3 Loading the cartridge assembly with Pulsar® Infinity
Tablets
WARNING - Use ONLY Pulsar® Infinity Tablets in the feeder. The
use of any other treatment chemicals will void the warranty and
NSF listing. DANGER: Under no circumstances should you mix
calcium hypochlorite with other forms of concentrated chlorine
or other chemicals. Fire and/or explosion may result. Caution
must be used when refilling the cartridge with more tablets.
WARNING - Wear protective gloves when handling Pulsar® Infini-
ty Tablets. Refer to Safety Data Sheets for additional information
and precautions regarding the use and handling of the tablets.
WARNING - KEEP OUT OF REACH OF CHILDREN
1. Prior to removing the pressure cap, open the Ball Valve at the
drain and drain the solution into a bucket or down to a drain
(figure 14). Caution: Failure to perform this step may result in
a chlorine spill and possible injury.
2. Remove pressure cap. See figure 15a & 15b.
3. Load tablets (figure 16a & 16b, page 19).
4. See figure 17 (page 19).
5. Verify that O-ring is still in place and there is no debris in the
O-ring groove before replacing seal cap (figure 18, page 19).
6. Replace seal cap (figure 19, page 20).
7. To tighten pressure cap, follow the steps written on the top
housing of the feeder as shown in Figure 20, page 20.
8. Align white dot on handle with white dot on housing cap (figure
21, page 20).
9. Twist cap clockwise to align white dot on handle with arrow on
top housing (figure 22, page 20).
Figure 15b
Figure 15a
1
2
Figure 14
Drain
