Pulsar Infinity PS-2SD - Installation Kit View (Standard Installation)

Pulsar® Infinity Operation and Installation Manual – Water Treatment 23
73098
Bolts
73098
Nuts
73097
Rubber
Grommet
7.2 Installation Kit View (Standard Installation)
Note: Quantities listed below represent the number of parts shipped with the feeder. Part numbers are for procurement of 1 individual spare part
unless otherwise stated.
Note: Refer to Appendix A for Pitot Tubes for 2 ½” and 3” pool piping
Part Description Qty Part Number
Saddle Clamp 1 1/2" to 2" [38.1 mm to 50.8 mm] Adjustable Saddle Clamp 2 73096
Rubber Grommet Seal for Saddle clamp 2 73097
Nuts and Bolts For saddle clamps, 4 pack 1 73098
Pitot Tube 5" x 1/2" [127 mm x 12.7 mm] NPT, 45° angle cut, 2 pack 1 73086
Ball Valve 1/2" [12.7 mm] female threaded 4 74061
Tubing Connector 5/8" [15.9 mm] O.D. Tubing Connector, W10MC8 4 71918
Tubing 12' x 5/8" [365.8 cm x 15.9 mm] O.D. x 1/2" [12.7 mm] I.D. LLDPE Tubing 1 73095
Closed Nipple 1/2” [12.7 mm] PVC Closed Nipple for Drain Port 2 (1 spare) 71611
Strainer Line strainer assembly 1 71605
73096
Saddle Clamp
74061
1/2” [12.7 mm]
Ball Valve
73086
Pitot Tube
73095
5/8” [15.9 mm]
O.D. Tubing
71918
5/8” [15.9 mm]
O.D. Tubing Connector
