Pulsar Ultra 3 - Product Specification

Page 5
Product Specification
Physical
Wall Mount
Outside dimensions 7.6 x 6.1 x 4.0 inch
(188 x 160 x 107 mm)
Weight Nominal 2.2lbs (1 kg)
Enclosure material/description Polycarbonate, flame resistant to
UL94-5V
Cable entry detail 8 cable entry knock outs, 3 x M20
1 x M16 underside, 4 x PG11 at rear
Fascia Mount
Outside Dimensions 7.87 x 4.41 x 4.25 inch
(200 x 112 x 108mm)
Weight Nominal 2.8lbs (1.3kg)
Enclosure material/description Stainless Steel back, Polycarbonate
UL94-V0 front and bezel
Transducer cable extensions 3-conductor 20 AWG screened
Maximum separation 3,280 ft. (1000 m), 1,640 ft. (500m) for
dBR16
Environmental
Mounting - Wall Mount Indoor/Outdoor
- Fascia Mount Indoor
Relative Humidity (IP Rating)
- Wall Mount IP65 (NEMA 4X) when closed, IP20
when open.
- Fascia Mount (IP64 from front panel) <35
o
C (95
o
F) at
93% relative humidity
Pollution Degree 2
Altitude 2000m maximum
Max. & min. temperature (electronics) -4
o
F to 120
o
F (-20 ºC to +50 ºC)
Flammable atmosphere approval Safe area: compatible with approved
dB transducers (see transducer spec'
sheet)
Approvals
UL Certificate Number E257330
CE approval See EU Declaration of Conformity
Performance
Accuracy 0.25% of the measured range or 0.24"
(6 mm) whichever is greater
Resolution 0.1% of the measured range or 0.08"
(2 mm) whichever is greater
Max. range Dependant on application and
transducer (maximum 131ft (40m)
dB40 dependant on application)
Min. range Dependent on application and
transducer (minimum zero dB Mach 3)
Rate response fully adjustable
Echo Processing
Description DATEM (Digital Adaptive Tracking of
Echo Movement)
