Pulsar Ultra 3 - Alarms

Page 130
Alarms
P210, 220, 230 =1 (Alarm)
The second parameter for each relay determines the function of the alarm.
P211, P221, P231 - Relay Function
This parameter defines what function the alarm will respond to as follows.
Option
Description
0= Off (Default)
Relay will not operate.
1= Level
Alarm is based on the level in the vessel, and the
type of level alarm (P212, 222, 232) and two
setpoints must be set (P213, 223, 233 & P214, 224,
234). Setpoints are entered in Display Units or %
of span as referenced to Empty Level*.
2= Rate of Change
Alarm is based on the rate of change of level in the
vessel, and the type of rate of change alarm (P212,
222, 232) and two setpoints must be set (P213,
223, 233 & P214, 224, 234). Setpoints are entered
in Display Units per minute or % of span per
minute and a negative value should be entered for a
Rate Alarm on a de-creasing level, and a positive
value for an increasing level.
3= Temperature
Alarm is based on the temperature, and the type of
temperature alarm (P212, 222, 232) and two
setpoints must be set (P213, 223, 233 & P214, 224,
234). The temperature used depends on the
temperature source selected (P852). Setpoints are
entered in
o
C.
4= Loss of Echo
Alarm is raised if the Failsafe Timer (P809)
expires. No setpoints are required.
5= Loss of Clock
Alarm is raised if the real-time clock fails. No
setpoints are required.
Note that the loss of echo and loss of clock will also be shown on the
display as “LOST ECHO” and “LOST CLOCK” respectively.
