Pulsar Ultra 3 User Manual

Page 132
Alarm ID
Description
Setpoints
6= In bounds
Relay goes “ON” if
value is inside the zone
between the two
setpoints.
Relay Setpoints,
P213, 223, 233 and
P214, 224, 234 can
be set in any order
as the unit ‘knows’
that you are setting
an inbounds alarm.
7= Out of bounds
Relay goes “ON” if
value is outside the zone
between the two
setpoints.
Relay Setpoints
P213, 223, 233 and
P214, 224, 234 can
be set in any order
as the unit ‘knows’
that you are setting
an out of bounds
alarm.
The fourth parameter and the fifth parameter for each relay set the
Alarm “ON” and “OFF” points. For a high alarm the “ON” is set higher
than “OFF”. For low alarm then “ON” is set lower than “OFF”. See the
appropriate alarm ID, table (P212, 222, 232) for further information.
When P211, 221, 231 = 1 (Level), 2 (Rate of Change) or 3 (Temperature)
P213, P223, P233 - Relay Setpoint 1
Determines the “ON” or “OFF” point for the alarm according to the ID
selected.
P214, P224, P234 - Relay Setpoint 2
Determines the “ON” or “OFF” point for the alarm according to the ID
selected.
