Pulsar Ultra 3 - Page 155

Page 147
P601-P603 Vessel Dimensions
These three parameters are used to enter the dimension required to calculate
the volume. The dimensions required are as shown below and are entered
Measurements Units (P104).
Vessel Shape
P601
P602
P603
P600=0
Cylindrical Flat base
Cylinder
Diameter
P600=1
Rectangular Flat base
Width of
rectangle
Breadth of
rectangle
P600=2
Cylindrical Cone base
Height of
base
Cylinder
Diameter
P600=3
Rectangular Pyramid base
Height of
base
Width of
rectangle
Breadth of
rectangle
P600=4
Cylindrical Parabola base
Height of
base
Cylinder
Diameter
P600=5
Cylindrical Half-sphere base
Cylinder
Diameter
P600=6
Cylindrical Flat sloped base
Height of
base
Cylinder
Diameter
P600=7
Rectangular Flat sloped base
Height of
base
Width of
rectangle
Breadth of
rectangle
P600=8
Horizontal cylinder flat ends
Length of
Cylinder
Cylinder
Diameter
P600=9
Horiz. Cyl. parabolic ends
Length of
Cylinder
Cylinder
Diameter
Length of
one end
section
P600=10
Sphere
Sphere
Diameter
P604 Calculated Volume
This parameter displays the maximum volume that has been calculated by
the Ultra 3 and is a Read-Only parameter. The volume displayed will be
shown in Volume Units (P605) and is the total volume available between
empty level (P105) and 100% of span (P106).
