Note
If you have already setup a common application, then there will be a number
shown other than 0, and you will see messages showing what the current
setup is. If you want to reset this and start again, press 0 (which will reset all
the quick setup parameters), otherwise pressing ENTER will allow you to
edit the parameters that have been set.
Choose Your Application
There are three categories of application, which are all described later in this
chapter. They are level, pump down (sump control) or pump up (reservoir
control) all with the choice of alarms.
If you want to set-up a basic level monitoring application, as described in
the following example 1, then choose 1.
If you want to set-up a pump down (sump control) application, as described
in the following example 2 then choose 2.
If you want to set-up a pump up (reservoir control) application, as
described in the following example 3 then choose 3.
Once you have chosen your application you will be asked a series of
questions which are answered by choosing the appropriate option as detailed
in the flow chart below. Once all the questions have been answered you will
be prompted to provide further information, as detailed in the tables below,
in order to complete the programming of the unit.
