6
WIRING CONNECTION
For 4 x 40W System
GREEN
GREEN/BLACK
GREY
GREY/BLACK
VIOLET
VIOLET/BLACK
MAIN UNIT
WHITE
WHITE/BLACK
FRONT Lch
SPEAKER
REAR Lch
SPEAKER
FRONT Rch
SPEAKER
REAR Rch
SPEAKER
Rch RED
Lch WHITE
(GREY)
REAR RCA CABLE
ANTENNA SOCKET
RED
YELLOW
BLACK
BLUE
POWER
ANTENNA
GROUND (B–)
MEMORY
BACK-UP
IGNITION
SWITCH (B+)
CD CHANGER
CONNECTOR
SOCKET
Rch RED
Lch WHITE
(YELLOW)
AUX IN
(BLACK)
WIRING REMOTE
CONNECTOR
SOCKET
(BLACK)
FUSE

Table of Contents

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Pyle PLCD15MR and is the answer not in the manual?

Pyle PLCD15MR Specifications

General IconGeneral
MP3 playbackYes
USB direct playbackNo
Supported radio bandsAM, FM
Preset stations quantity30
Line outputs (RCA)2
Output power240 W
Product color-
Volume controlDigital
Weight and Dimensions IconWeight and Dimensions
Depth177.79 mm
Height49.78 mm
