6 —TECHNICAL DATA
RELEASE 1.0.1 —15 JULY, 2020
3 Technical data
3.1 Mechanical dimensions
The figurebelow shows the overall dimensions of the qb SoftHand research, valid for both left and right
configurations;distancesand tolerances in the drawing are noted in millimeters[mm]and degrees[°].
Figure 1. — qb SoftHand drawings
WARNING:
Be aware that the above figure may be out of scale.

