Pi HSC816 Installation Manual - Revision Beta
This document and product are copyrighted and all rights are reserved.
Location 4: Trigger action (Wireless triggers)
Wireless triggers can only be timed and location 4 must be selected as a zero for a single transmission. If a
trigger number is inserted in location 4 this trigger number will transmit once at the end of the trigger timer
When used with the AC SWITCH an on and off condition can be used, in which case the trigger number
programmed in L3 will switch the AC switch on with the selected condition and the Trigger number 1 to A
programmed in location 4 will be the off signal that will be sent when the trigger timer expires.
QUESTION 166 to 168: Wireless triggers timers
QUESTION 166
Location 1 = Trigger 1 Location 2 = Trigger 2
Location 3 = Trigger 3 Location 4 = Trigger 4
QUESTION 167
Location 1 = Trigger 5 Location 2 = Trigger 6
Location 3 = Trigger 7 Location 4 = Trigger 8
QUESTION 168
Location 1 = Trigger 9 Location 2 = Trigger 10
Location 3 = Reserved Location 4 = Reserved
QUESTION 175: Point Id Table
This relates to the QD serial or DTMF transmitters pre xxxxx with limited point id.
Location 1 = Point id Location 2 = Reserved
Location 3 = Reserved Location 4 = Reserved
Location 1
QUESTION 176 to 232: Reporting codes
Location 1 and 2 relate to the full Ademco point id table. (See table B)
Location 3 and 4 relate to the restricted Ademco point id table (See table A)
