c. Hold the module by the edges.
d. Carefully slide the module out of the slot.
Warning
• Do not touch the internal components, particularly the metal connectors.
• Do not bend the module.
6. Install a new module.
a. Align the notch with the ridge in the slot.
b. Insert the module into the slot.
c. Verify that the metal connectors are completely inserted into the slot.
TS-hx90FU User Guide
Installation and Conguration 28
