Expansion Unit
Model
Description Required Accessories
TR-004 • Uses a USB 3.2 Gen 1 Type-C
interface
• Supports SATA drives
• USB 3.2 Gen 2 Type-A to Type-C
cable
• USB 3.2 Gen 2 Type-C to Type-C
cable
TR-004U • Uses a USB 3.2 Gen 1 Type-C
interface
• Supports SATA drives
• USB 3.2 Gen 2 Type-A to Type-C
cable
• USB 3.2 Gen 2 Type-C to Type-C
cable
• RAIL-B02
TL-D800C • Uses a USB 3.2 Gen 2 Type-C
interface
• Supports SATA drives
• USB 3.2 Gen 2 Type-A to Type-C
cable
• USB 3.2 Gen 2 Type-C to Type-C
cable
TL-R1200C-RP • Uses a USB 3.2 Gen 2 Type-C
interface
• Supports SATA drives
• USB 3.2 Gen 2 Type-A to Type-C
cable
• USB 3.2 Gen 2 Type-C to Type-C
cable
• RAIL-B02
Connecting SAS Expansion Units
To connect the device to SAS expansion units, a storage expansion card must be installed in the device.
For required accessories details, see Expansion Unit Installation.
1. Install a storage expansion card on the PCIe slot.
For details, see Replacing Expansion Cards.
2. Connect the expansion units to the device using the following topology.
TS-h3088XU-RP User Guide
Installation and Configuration 31
