c. Hold the edges of the module and carefully pull it out of the slot.
Warning
Attempting to remove a module that is not completely released may damage the
module and the motherboard.
7. Install a new module.
a. Align the notch with the ridge in the slot.
b. Insert the module.
c. Verify that the metal connectors are fully inserted.
d. Carefully press down on the module until the retention clips lock the module into place.
TVS-x72XT User Guide
Installation and Conguration 41
