Conguring TCP/IP Settings
You can congure the following settings for each network adapter on the device:
• IP address
• Subnet mask
• Default gateway
• Primary DNS
• Secondary DNS
1. Press Enter or Select.
The panel displays the NAS name and QTS version.
2. Press and hold Enter for two seconds.
The panel displays Main Menu 1. TCP/IP.
3. Press and hold Enter.
The panel displays the IP address of the rst network adapter.
4. Press Select repeatedly until the panel displays Enter Network Settings.
5. Press and hold Enter.
The panel displays the congurable network settings.
6. Press Select and then Enter to congure the settings.
Button Usage
Enter • Display a conguration screen.
• Move to the next item on a conguration screen.
Select • Move to the next item on a menu.
• Modify a value on a conguration screen.
7. After conguring the settings, press Select repeatedly until the panel displays Network
Restart.
Important
If you do not see Network Restart, the system will not save the congured settings.
The system saves the settings.
Viewing Drive Information
The LCD panel can display the temperature and capacity of each drive installed in the NAS.
