QSC ISA280 - Main PCB Assembly ISA280

26 QSC Audio Products, LLC
TD-000163-00 Rev. B
SC-030004-GP M3 X 8 BLK MACHINE 16
SC-030005-GP M3 X 12MM (BLK/ZINC) 4
SC-030011-GP M3 X 8 MM NICKEL 2
SC-040007-GP PHILLIPS, SERRATED M4X20L BLK 4
SC-040008-GP P/P, M4, 10MM, BLK, TRIANGULAR TIP 10 ALT. P/N: SC-040001-GP
SW-000086-GP CIRCUIT BRKR 10AMP 1 100V and 120V only
SW-000088-GP ROCKER POWER SWITCH 1
SW-000093-GP CIRCUIT BREAKER, 5 AMP, , 1 230V only including UK
and Korea only
WC-000169-GP CONN ASSY 2PIN ISA 2
WC-000171-GP CONN ASSY 3-PIN 1
WC-000173-GP CONN ASSY 4P P2.5 L=200 AWG26 2
WC-000174-GP CONN ASSY 6-PIN ISA 280 1
WC-000175-GP CONN ASSY 8P P2.5 L=460 AWG26 1
WC-000177-GP UL1015 #14 2P GRN L=100 1
WC-000179-GP UL1015 #16 3P BRN L=360 2
WC-000180-GP UL1015 #16 2P OFFWHITE 2
WC-000182-GP CONN ASSY 13P P2.0 L=240 1
WC-000192-GP UL 2547 3-PIN P2.5 L=250 2
WC-000198-GP GROUND WIRE 1
WC-000199-GP UL 1015 AWG#14 BROWN 1
WC-000211-GP WIRE ASSY, FAN GROUND 1
WP-000076-00 SRV - XFMR MOUNTING ASSY 1
WP-002801-00 MAIN PCB ASSY, ISA 280 1 Panelized assembly; see
WP-002801-00 list for
individual channel
modules
WP-004502-00 PCB ASSY, AC/INPUT ISA (120V) 1 100V and 120V only;
Panelized assembly; see
WP-004502-00 list for
individual channel
modules
WP-004502-02 PCB ASSY, AC/INPUT, ISA, 230V, 1 230V including Korea
and UK only; Panelized
assembly; see
WP-004502-02 list for
individual channel
modules
XF-000193-GP PWR XFMR ISA 280/300T 1
Main PCB Assembly ISA280
QSC part # WP-002801-00
This assembly is a panelized construction comprising the two channel modules, built on a common perforated circuit board. For the
channel 1 module (the one on top), order PCB-QZ040C-PWR1; for the channel 2 module (the one underneath), order PCB-QZ040C-
PWR2.
QSC Part # Description Qty. Reference Comments
CA-056001-GP CC 50V 56PF 10% 0805 2 C110, C210
CA-056002-GP CTC 200V 56PF 5% 1206 2 C111, C211
CA-118000-GP CC 50V 180PF 5% 0805 4 C101, C103, C201, C203
CA-122005-GP CC 50V 220PF 5% 0805 4 C20–C23
CA-210011-GP 0.001UF 5% 100V CER X7R 1206 2 C114, C214
CA-222007-GP 50V .0022UF 10% 1206 4 C115, C126, C215, C226
CA-233004-GP CM 50V .0033UF 5% RL 4 C117, C118, C217, C218
CA-310009-GP CC 50V .01UF 20% 0805 1 C5
CA-322006-GP CM 50V .022UF 5% RL 4 C116, C119, C216, C219
CA-322007-GP CC 50V .022UF 10% 0805 2 C125, C225
CA-368004-GP 0.068UF 5% 250V FILM DIPPED 2 C124, C224
CA-382001-GP 0.082U, 5%, 63V, CM, , RBT, 7.5 2 C109, C209
CA-410013-GP CER 2 1206 10% 50V .1UF 3 C100, C102, C104
CA-410014-GP 0.1UF 10% 50V CER X7R 0805 1 C11
CA-415004-GP 0.15U, 5%, 63V, CM, , RBT, 7.5X 2 C108, C208
CA-422006-GP CM 50V .22UF 5% RL 2 C107, C207
Chassis Assembly ISA280 (before May 2006) continued
QSC Part # Description Qty. Reference Comments
